India
India
50 - 105 HP
1202 - 1704 mm
CAT-II
| MODEL | A-PDH6 | A-PDH7 | A-PDH8 |
| FRAME | 140 mm OD Round Tube | 140 mm OD Round Tube | 140 mm OD Round Tube |
| GANG AXLE | 90 mm OD Round Tube with 90 m Solid Ends | 90 mm OD Round Tube with 90 m Solid Ends | 90 mm OD Round Tube with 90 m Solid Ends |
| NO. OF DISC | 6 | 7 | 8 |
| TYPE OF DISCS | Notched or Plain (Optional) | Notched or Plain (Optional) | Notched or Plain (Optional) |
| DISC DIAMETER | 610 mm /660 mm | 610 mm /660 mm | 610 mm /660 mm |
| DISC SPACING | 264 mm | 264 mm | 264 mm |
| BEARING HUBS | 2 (Heavy Duty) | 2 (Heavy Duty) | 2 (Heavy Duty) |
| TILLAGE WIDTH (MAX.) | 1202 mm | 1453 mm | 1704 mm |
| LINKAGE | Trailed & Mounted (Both) | Trailed & Mounted (Both) | Trailed & Mounted (Both) |
| GANG ANGLE ADJUSTMENT | Manual / Hydraulic | Manual / Hydraulic | Manual / Hydraulic |
| APPROX WEIGHT | 510 Kg. | 555 Kg. | 605 Kg. |
| TRACTOR POWER | 50 - 70 HP | 70 - 90 HP | 90 - 105 HP |
* The Weight and working data contained are supplied for information only and are not binding. Specification and size can be altered as a part of ongoing product modification / improvement.
